77250610 ชาร์ปอก 0.25 (010) BENZ/MTU OM444 SPUTTER ชาร์ปพิเศษ TURBO KS GERMANY แท้
Product description
| Repair grade | 0.25 mm |
Specifications
| Qty. | design 1 | bearing position | material 2 | bearing width | wall thickness | shaft diameter | housing bore | Distance crank web | axial clearance |
| 6 | HL |  |
St/B/G1 | 30.50 mm | 3.597 mm | 103.730 mm 103.750 mm |
111.000 mm 111.022 mm |
||
| 6 | HL |  |
St/B/S | 36.00 mm | 3.597 mm | 103.730 mm 103.750 mm |
111.000 mm 111.022 mm |
||
| 1 | PASS-L | St/B/G | 38.31 mm | 3.599 mm | 103.730 mm 103.750 mm |
111.000 mm 111.022 mm |
38.500 mm 38.562 mm |
0.190 mm 0.322 mm |
Product description
| Repair grade | 0.25 mm |
Specifications
| Qty. | design 1 | bearing position | material 2 | bearing width | wall thickness | shaft diameter | housing bore | Distance crank web | axial clearance |
| 6 | HL | |
St/B/G1 | 30.50 mm | 3.597 mm | 103.730 mm 103.750 mm |
111.000 mm 111.022 mm |
||
| 6 | HL | |
St/B/S | 36.00 mm | 3.597 mm | 103.730 mm 103.750 mm |
111.000 mm 111.022 mm |
||
| 1 | PASS-L | St/B/G | 38.31 mm | 3.599 mm | 103.730 mm 103.750 mm |
111.000 mm 111.022 mm |
38.500 mm 38.562 mm |
0.190 mm 0.322 mm |
