92-25003 บ่าวาล์วไอเสีย MAN (45 องศา) KS GERMANY แท้

valve seat angle (α) 45.0 °
outside diameter (D) (mm) 53.11 mm
inside diameter (d) (mm) 43.0 mm
height (H) (mm) 9.9 mm
outside diameter (D) (inch) 2.091 inch
inside diameter (d) (inch) 1.693 inch
height (H) (inch) 0.39 inch

Outer Diameter Valve seat insert		Material Cylinder Head Cast iron		Material Cylinder Head aluminium
[mm]	[inch]	[mm]	[inch]	[mm]	[inch]
20 – 30	0.7874 -1.1811	0,06	0.0024	0,08	0.0031
30 – 40	1.1811 -1.5748	0,08	0.0031	0,105	0.0040
40 – 50	1.5748 -1.9685	0,10	0.0040	0,12	0.0047
50 – 60	1.9685 -2.3622	0,12	0.0047	0,14	0.0055
60 – 70	2.3622 -2.7559	0,14	0.0055	0,16	0.0063
